Pinarello Granger X1

Pinarello Granger X1
  • Color: Organge
  • Color: Black on Black
  • Color: Green Sand
$2,999.99 - $3,799.99
$3,799.99
Color: Organge
Size: Select size
Please select options Unavailable
This item is not permitted to be shipped, however it can be purchased online and picked up at your convenience. PLEASE, Call ahead to check on availability.

Details

YOUR ULTIMATE ADVENTURE MATE.
Get ready to step into your next epic adventure. No matter how long or how far, just ride, get lost while exploring, and find your inner soul. It's all about the experience, exploring new destinations, and sharing it while you are in the most remote places on Earth.

CARBON T600UD
A comfort-optimized carbon fiber structure with an unidirectional finish that absorbs all road vibrations for a pleasurable and comfortable ride.

ASYMMETRIC FRAME
For first Pinarello understood that, while the thrust applied to both pedals is the same, the pull on the chain applies to the right side only. For this reason, all frames are optimized to compensate for these unbalanced forces.

ONDA FORK
A distinctive Pinarello Technology since 2000. The shape of the fork delivers precise turning abilities, stability, and reduction of longitudinal and lateral shocks.

Sizes:
Size4750535557.560
Seat Tube Center - End (mm) - - - - - -
Seat Tube Center - Center (mm) - - - - - -
Top Tube Center - Center (mm) 522 535 550 565 582 600
Seat Tube Angle (°) 74.5° 74° 73.75° 73.5° 73° 72.5°
Headtube Angle (°) 69.75° 70° 70.25° 71° 71.25° 71.5°
Chainstay (mm) 430 430 430 430 430 430
Headtube (mm) 125 137 155 169 185 202
BB Drop (mm) 72 72 72 72 72 72
Fork Rake (mm) 50 50 50 47 47 47
Fork Height (mm) 395 395 395 395 395 395
Reach (mm) 363 369.9 378.4 386.9 394.5 402.2
Stack (mm) 543.4 555.7 573.6 590.8 607 624.1

Specs

Frame TorayCa T600 UD, Internal Cable Routing, Italian BB
Fork Grevil onda fork with forkflap™, tapered head tube
Bottom Bracket Shimano GRX
Crankset Shimano GRX 600 2X
Rear Derailleur Shimano GRX 600 2X
Cassette/Freewheel Shimano GRX
Chain Shimano GRX
Brakes Front: Shimano GRX, 2 pistons caliper, 160mm rotor
Rear: Shimano GRX, 2 pistons caliper, 160mm rotor
Handlebars Jaguar XA Aero TiCR
Tape/Grips MOST Ultragrip Evo 3mm - Black
Stem Tiger Aero Alu TiCR
Seatpost MOST alu round seatpost
Saddle Most Lynx Aircross FEC Alloy Large 145mm
Accessories & Extras Seat Clamp: FSC frontal seat clamp

* Subject to change without notice.

Part Numbers

Option MPN Store SKU
Organge / 47 D1610008146-00013
Organge / 50 D1610008146-00014 GRA23312010
Organge / 53 D1610008146-00015 GRA232481923
Organge / 55 D1610008146-00016
Organge / 57.5 D1610008146-00017
Organge / 60 D1610008146-00018
Black on Black / 47 D1610008146-00001
Black on Black / 50 D1610008146-00002
Black on Black / 53 D1610008146-00003
Black on Black / 55 D1610008146-00004 PIN316537675
Black on Black / 57.5 D1610008146-00005
Black on Black / 60 D1610008146-00006
Green Sand / 47 D1610008146-00007 PIN327589897
Green Sand / 50 D1610008146-00008
Green Sand / 53 D1610008146-00009 PIN326025563
Green Sand / 55 D1610008146-00010 PIN326113615
Green Sand / 57.5 D1610008146-00011
Green Sand / 60 D1610008146-00012
